Microsoft SQL Server

Connect to SQL Server and Azure SQL Database with the FreeTDS-based driver plugin

Microsoft SQL Server Connections

TablePro connects over TDS 7.4 via FreeTDS, which SQL Server 2012 and later speak. This covers instances on Windows, Linux, and Docker, plus Azure SQL Database. FreeTDS is statically linked into the plugin, so there is nothing to build or install besides the plugin itself.

Install Plugin

The SQL Server driver is a downloadable plugin. When you select SQL Server in the connection form, TablePro prompts to install it. To install manually:

1. Open Settings > Plugins > Browse
2. Find MSSQL Driver and click Install
3. The plugin downloads and loads immediately, no restart needed

See Plugins for how plugin installs and updates work.

Connection Settings

Click New Connection, select SQL Server, fill in the fields, and click Save & Connect.

Field	Default	Notes
Host	localhost	Named instances are not supported; use the host and TCP port
Port	1433
Authentication	SQL Server Authentication	Or Windows Authentication (Kerberos) on macOS. See Windows Authentication below
Username	-	SQL Server login name. Hidden when Windows Authentication is selected
Database	-	Optional. Sent during login when set, which is required for logins scoped to one database, such as Azure SQL contained users
Schema	dbo	Active schema after connecting. Clear it to use the login’s default schema, which the driver reads with SELECT SCHEMA_NAME()

SQL Server connection form

For Azure SQL Database, set the host to yourserver.database.windows.net and pick SSL mode Required or stricter.

Windows Authentication (Kerberos)

Available on macOS. Set Authentication to Windows Authentication (Kerberos) to sign in with your domain identity instead of a SQL Server login. On macOS, Windows Authentication means Kerberos; NTLM is not supported.

There are two ways to sign in:

• Use your existing ticket (single sign-on). Leave the Kerberos principal and password blank. TablePro uses the ticket already in your credential cache. Get one first with kinit:

  kinit [e-mail]
  klist            # confirm a krbtgt/[e-mail] ticket exists


• Sign in with a principal and password. Enter the Kerberos principal ([e-mail]) and your domain password. TablePro requests a ticket for that principal, then connects.

Requirements:

• Connect by hostname, not IP address. Kerberos targets the service principal name MSSQLSvc/host.domain.com:1433, which is registered against the host name.
• Uppercase realm. The realm is usually the DNS domain in uppercase, for example CONTOSO.COM.
• Realm resolution. Your Mac must be able to find the domain’s KDC, either through DNS SRV records or an /etc/krb5.conf entry.
• A registered SPN. The SQL Server service account must have an SPN such as MSSQLSvc/host.domain.com:1433. Ask your administrator if connections fail with an SSPI or service-principal error.

Servers in another realm

If the SQL Server lives in a different Kerberos realm than your Mac’s default_realm, map its DNS domain to that realm in /etc/krb5.conf:

[domain_realm]
  .sql.example.com = RESOURCE.REALM.COM

TablePro reads that mapping and asks the KDC for a ticket in RESOURCE.REALM.COM, so a cross-realm trust works without changing default_realm. This is the same mapping the JDBC driver uses, so a server that already works in DataGrip works here.

With no [domain_realm] entry for the host, TablePro falls back to default_realm, which is what a single-realm domain needs.

TablePro does not run kinit or edit /etc/krb5.conf for you; those are set up once per machine.

Connection URL

sqlserver://user:password@host:1433/database
mssql://user:password@host:1433/database

See Connection URL Reference for all parameters.

Databases and Schemas

The sidebar groups tables by schema and hides the built-in role schemas (db_owner, guest, and the rest). Switch the active database with Cmd+K; switches happen in place, no reconnect. Pick the active schema from the schema menu in the sidebar. master, tempdb, model, and msdb are marked as system databases.

Features

• Table structure: columns, indexes, foreign keys, triggers, and generated CREATE TABLE DDL.
• IDENTITY columns: INSERTs generated by the data grid omit IDENTITY columns, so the server assigns the value.
• Pagination: browse queries use OFFSET ... FETCH.
• Large text: TEXTSIZE is raised at connect, so nvarchar(max) and text values are not truncated to the 2048-byte FreeTDS default.
• Query control: running queries can be cancelled; the query timeout maps to SET LOCK_TIMEOUT.
• View templates: use CREATE OR ALTER VIEW on SQL Server 2016 and later, plain CREATE VIEW (drop first when editing) on older versions.

SSL/TLS

TablePro maps the SSL mode to FreeTDS DBSETENCRYPT. New connections default to Preferred.

Mode	FreeTDS value	Behavior
Disabled	off	Plain TCP
Preferred	request	Try TLS, fall back to plain if the server cannot
Required	require	TLS required
Verify CA	require	Same as Required; dblib does not accept a CA path per connection
Verify Identity	require	Same as Required

Certificate verification beyond the system trust store is configured machine-wide in freetds.conf, not per connection. See SSL/TLS for concepts.

Google Cloud SQL

SQL Server connections can run through the Cloud SQL Auth Proxy; TablePro starts and stops the proxy for you. See Cloud SQL Auth Proxy.

Troubleshooting

Connection refused: enable TCP/IP in SQL Server Configuration Manager, confirm the service is running, check firewall port 1433, and if using Docker confirm the container is up.

Login failed: verify credentials, then check the server allows SQL Server Authentication: SELECT SERVERPROPERTY('IsIntegratedSecurityOnly') returns 1 when only Windows Authentication is allowed. Enable mixed mode in SSMS under Server Properties > Security, then restart the service. If the login only has access to one database (an Azure SQL contained user), set the Database field; TablePro sends it during login. Without it the server authenticates against master and rejects the login.

Windows Authentication fails: run klist to confirm you have a ticket, and kinit [e-mail] if you do not. Connect by hostname, not IP address. An SSPI or “server not found in Kerberos database” error means the server’s SPN is not registered, or it is registered in a realm your Mac does not map the host to; ask your administrator to register MSSQLSvc/host.domain.com:1433, and if the server is in another realm add a [domain_realm] entry as shown in Servers in another realm. A clock-skew error means this Mac’s clock is too far from the domain controller; turn on Set time automatically in System Settings.

Limitations: no Microsoft Entra ID (Azure AD) authentication, Windows Authentication (Kerberos) is macOS only, named instances unsupported (use host and port), Verify CA and Verify Identity behave like Required.
